Lowboy Trailer
The Lowboy Trailer is a multi-axle, low-chassis transport vehicle suitable for road transport of overweight, overwidth, and overlength goods.
Features
Introduction
The Lowboy Trailer is a multi-axle, low-chassis transport vehicle suitable for road transport of overweight, overwidth, and overlength goods. Its applications include loading and transporting construction machinery, power generation equipment, and large components, as well as site relocation.
Specification
|
Item |
Details |
|
Product Model |
China Lowboy Trailer Factory |
|
Overall Dimensions (L×W×H) |
16000mm × 2500mm × 1600mm |
|
Curb Weight |
Approx. 21 tons (subject to factory inspection upon delivery) |
|
Axle Configuration |
10 axles (equipped with air suspension lift axles, height-adjustable) |
|
Tire Specification |
12.00R22.5 heavy-duty radial tires (optional brands: Triangle, Linglong, Chaoyang, etc.) |
|
Rim Specification |
8.5-22.5 steel rims |
|
Kingpin |
2-inch / 3.5-inch interchangeable |
|
Main Beam Height |
500mm (Material: Q345 high-strength steel) |
|
Upper Flange Thickness |
20mm |
|
Lower Flange Thickness |
20mm |
|
Web Plate Thickness |
12mm |
|
Brake System |
Dual-circuit pneumatic brake system (equipped with WABCO emergency relay valve + ABS anti-lock braking system), ensuring braking safety on complex road conditions |
|
Core Customized Configurations |
1. Air suspension lift axles (adapts to bridge weight/height limits, flexibly adjusts vehicle height);2. Rear hydraulic lifting ramp (facilitates loading/unloading of self-propelled equipment);3. 100mm-high side panels (suitable for transporting small bulk goods) |
Features
Multi-axle Air Suspension
Equipped with 10 axles and air suspension lift axles, the vehicle height can be adjusted according to bridge load and height restrictions to evenly distribute the vehicle load to each axle.
High-Strength Main Beam
The main beam is 500mm high, made of Q345 high-strength steel, with a flange thickness of 20mm and a web thickness of 12mm, designed to withstand longitudinal bending moments and lateral shear loads.
Multi-functional Side Plates
Equipped with 100mm high side plates for carrying small bulk cargo while also accommodating heavy equipment transport on low-bed trailers.
Applications
Construction Machinery Transportation Industry: Used for transporting excavators, bulldozers, and large construction equipment, enabling full-vehicle transfers within and outside construction sites.
Power Generation and Energy Equipment Transportation Industry: Used for transporting transformers, generator sets, and large power installations, enabling road transport from manufacturing plants to construction sites.
Infrastructure Construction Industry: Used for transporting bridge components, steel structure modules, and other large materials, coordinating with hoisting and construction scheduling to complete transportation tasks.
Heavy Industrial Equipment Transportation Industry: Used for transporting mining equipment, metallurgical equipment, and other heavy-duty industrial equipment, enabling cross-site or cross-regional handling.
Product Certification
FAQ
Q: Is the main beam structure suitable for heavy-duty transportation?
A: The main beam is made of 500mm high Q345 steel, with 20mm thick flanges and 12mm thick webs, capable of withstanding longitudinal bending moments and lateral shear under full load.
Q: What are the operating conditions for the hydraulic lifting ramp?
A: The ramp is operated by a hydraulic system and can be used for loading and unloading self-propelled equipment or low-chassis vehicles without additional support facilities.
Q: What is the role of the side plate height in transportation?
A: 100mm high side plates are used to support small bulk goods, preventing materials from slipping during transportation while maintaining the low-bed transport capacity.
